Bookeye® BE4-V2 Kiosk
Bookeye ® BE4-V2 Kiosk was designed specifically as a self service book scanner or self service book copier. A casual user, from any walk of life, can quickly and easily operate this device.
  • 400 dpi optical resolution
  • 50,000 hr lamp life
  • Book fold correction
  • Gigabit wired
  • V-shaped cradle 120-180 degrees
  • 19" preview screen
In libraries, archives and other public institutions, the Bookeye® BE4 V2 Kiosk is often found as an integral part of the infrastructure. Through the freely configurable touchscreen, the user interface of the scanner can be precisely matched to the requirements of the customers (and to their corporate identity).

The unique book cradle solution allows users to digitize bound documents at a resolution of 400 dpi and A2+ in size, by either lying them flat on the scanning bed or in the V-cradle, at an angle of 120 degrees.
BROCHURE

Overview

The unique book cradle solution allows users to digitize bound documents at a resolution of 400 dpi and A3+ in size, by either lying them flat on the scanning bed or in the V-cradle, at an angle of 120 degrees.


An integrated 19 inch preview monitor allows the operator to control image quality and make some modifications on the fly. Scanned images can be output to USB, eMail, network, printer or on a mobile device like an iPad or Anrdoid tablet.


SCAN2PAD® OPTION

The Bookeye® BE4 V2 Kiosk copier has an integrated billing module. This means that for all applications that do not have an existing card or billing system, Bookeye® BE4 V2 Kiosk can take over the billing itself. Configurable invoice printing and journalling are standard functions in the Bookeye® 4 V2 Kiosk as well as the remote locking / unlocking of the system.


For applications that do have an existing card or billing system, the Bookeye® 4 V2 Kiosk integrates with its billing interface. Examples of these kinds of billing systems include Schomäcker, Cartardis, Höhr or InterCard. For kiosk systems that can be operated offline, there is also the possibility of connecting a coin operation device.



BOOKEYE® BE4-V2 KIOSK FEATURES



  • LED lamps, no warm up, IR/UV free
  • Large color WVGA touchscreen for simplified operation
  • User interface configurable in your language
  • Large 19 inch preview screen
  • Virus resistant Linux operating system
  • Operating system independent, runs under Windows, Linux, Mac OS, Unix
  • Network scanning via any web browser; i.e. IE, Safari, Chrome, Firefox
  • Scan2Net®-technology
  • Easy installation
  • Remote maintenance and analysis
  • Web based firmware updates
  • Including 12 months Full Coverage Warranty




BOOKEYE® BE4-V2 KIOSK FUNCTIONS



  • Colour overhead scanner for A3+ formats
  • 400 x 400 dpi scanner resolution
  • V-shaped book cradle 120 - 180 degrees
  • Book Fold Correction - Scan bound documents without annoying shadows
  • Automatic finger and thumb removal
  • Automatic Crop & Deskew
  • Integrated billing module
  • Digital color balance
  • Integrated ICC-profile
  • Automatic white balance and black value
  • Scan2USB--Walk-up Scanning to USB Stick
  • Scan2Print--Output to any connected printer
  • Scan2Network--Output to any network driver
  • Wide color gamut: supports sRGB, Adone RGB, native RGB
  • Output formats PDF, PDF/A, JPEG, TIFF, PNM



BOOKEYE® BE4 V2 KIOSK OPTIONS

  • Foot Switch -- Hardware option for batch scanning
  • Upgrade Client-Interface & 600 dpi -- Software option to production scanner
  • Scan2ICC -- Subscription for ICC color management and profiles
  • Scan2TWAIN -- TWAIN driver for Client-Interface & 600 dpi)
  • Extended Warranty --Up to 5 years subscription for extended warranty package and free spare parts
Specifications

Maximum Document Size


Scanner Resolution:


Optical Resolution:


Pixel Dimension:


Scan Speed Colour:







Color Depth:


Scan Output:


File Formats:


Computer:


Interface:


Camera:


Light Source:


Lamp Life:


Dimensions Scanner:


Weight Scanner:


Electrical Connection:



Power Consumption:


Operating Temp:


Rel Humidity:


Noise:

460 x 620 mm (18 x 24.4 inch), 14% more than DIN/ISO A2


400 x 400 dpi


400 dpi


9.3 x 9.3 µm


DIN A2+ @ 150 dpi: 1.2 s

DIN A2+ @ 200 dpi: 1.6 s

DIN A2+ @ 300 dpi: 3.4 s

DIN A2+ @ 400 dpi: 4.6 s


36 bit colour, 12 bit grayscale,


24 bit colour, 8 bit grayscale, bitonal, enhanced halftone


PDF, PDF/A, JPEG, PNM, TIFF uncompressed, TIFF G4 (CCITT), Multipage PDF, TIFF


64 bit Linux, Intel i3, quad core processor, 8 Gigabyte RAM, 320GB HDD for extra large jobs


1 GBit Fast Ethernet with TCP/IP based Scan2Net(R) interface


CCD camera, 22,500 pixels


White LEDs, according IEC 60825-1: class 1, no IR/UV emission


50,000 h (typ.)


780 x 670 x 670 mm (30.7 x 26.4 x 26.4 inch) (H x W x D)


~40.5 kg (90 lbs.)


100-240 V AC, 47 - 63 Hz (external power supply, complies with ECO standard CEC level V)


≤ 0.5 W (Sleep) / 2.5 W (Standby) / 130 W (Scanning)


5 to 40 °C, 40 to 105 °F


20 to 80 % (non-condensing)


< 42 dB(A) (Scanning) / < 33 dB(A) (Standby)
